APC-TF Series MAINTENANCE
Thyristor protection
Thyristor protection
The thyristors in the APC-TF series controllers are protected in the following way:
· external high speed fuses against over-currents (except for short-wave infrared applications)
· RC snubbers and MOVs (varistors) protect against over-fast voltage variations and transient
over-voltages when the thyristors are not conducting.
*** MOVs (varistors) install : Optional
Nominal current Compatible Maker Remarks
30A IXYS, SEMIKRON
40,55A IXYS, SEMIKRON
70A IXYS, SEMIKRON
90A IXYS, SEMIKRON
110A IXYS, SEMIKRON
130A IXYS, SEMIKRON
160A IXYS, SEMIKRON
200A IXYS, SEMIKRON
250A IXYS, SEMIKRON
300A IXYS, SEMIKRON
400A POWEREX, SEMIKRON
500A POWEREX, SEMIKRON
* Recommended for compatible makers
DANGER!
If failure happens of the SCR, must be change to compatible maker’s.
To control the thyristors in the APC-TF series, 3 SCRs and bus-bar must be used.
Details of these are given in the following table for compatible maker.
Maximum operating voltage for THYSISTOR : 1600V (line-to-line).
