Estella 348DSC67 - Parts Diagrams

7.
COUNTERTOP MODEL
PARTS DIAGRAMS
No Description
Code
Qty
1 Hexagon screw
M8x20L
1
2 8 at pad 1
3 Gear 15T
TT520290
1
4 Gear 27T
TT520280
1
5 Gasket
TT520300
1
6 51108 Thrust Bearing 1
7 Bearing sleeve
TT520320
1
8 6004 bearing 1
9 C type 5x5x30L at key 1
10 Axis
TT520310
1
11
Conveyor wheel bearing
sleeve
TT520410
1 Set
12 6003 bearing
13 51103 Thrust Bearing
14
Aluminum blocks on both
sides of the roller
15 Roller shaft
16 Belt roller
TT520420
17 Bearing sleeve
TT520470
18 Adjusting bolt
M20x50*2
1
19 Plastic head screw
M10x78x30
1
20 M10 nut 1
21 10 spring pad 1
22 Fixed shaft
TT450920
1
23 35 hole circlip 1
1
10
100
2
3
4
5
6
7
8
9
11
12
13
14
15
17
18
16
32
28
29
30
31
33
34
35
37
36
38
39
40
41
42
43
44
45
91
92
93
94
95
96
97
98
99
104
101
105
106
107
108
102
103
109
110
19
20
21
22
23
24
25
26
27
:
:
:
:
:
:
SECTION NAME
DRW No.
Designer
Check
Review
Scale
Date
LEFT ROLLER
ASSEMLY
AND
TOP ROLLER
ASSEMBLY
-- --
-- --
-- --
-- --
-- --
-- --
-- --
-- --
-- --
-- --
-- --
-- --
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
DESCRIPTION
VERSION DESRIPTION
DATE
1st Drawing 2019/05/19A
B
C
D
E
F
DES IGNER
PRODUCT NAME
TABLE TOP
DOUGH SHEETER
TT-D18A
TT-D18B
LEFT ROLLER ASSEMBLY
AND TOP ROLLER
ASSEMBLY
LEFT ROLLER ASSEMBLY AND TOP ROLLER ASSEMBLY
No Description
Code
Qty
24 6202 bearing 1
25 Sprocket
TT520930
1
26 15 axis circlip 1
27
Hexagon socket head cap
screws
M10x40L
1
28 Socket head bolt
M6x20L
1
29 Cover
TT450040
1
30 25 circlip 1
31 Sprocket 21T
TT520500
1
32 6205 bearing 1
33 52 hole circlip 1
34 Washer 3mm 1
35 Eccentric block
TT520210
1
36 Wheel adjustment block
TT520101
1
37 Flat pad 3mm 1
38 Washer 6mm
TT520770
1
39 Arm
TT450020
1
40 M10 nut 1
41 10 spring pad 1
42 10x596 dental rod 1
43 Rubber sleeve
TT520720
1
44 Fixed rod
TT520710
1
45 Axis
TT520450
1
46 Arm
TT520010
1
No Description
Code
Qty
91 Hex bolts
M8x80L
1
92 8 spring pad 1
93 M8 nut 1
94 Tension spring
1.6x16x64
1
95 8 spring pad 1
96 M8 hat 1
97 Set screw
M8x12L
1
98 C type 6x6x25 at key 1
99 Upper roller sprocket
TT520510
1
100 6205 bearing 1
101 A type 6x6x18 at key 1
102 A type 6x6x18 at key 1
103 C type 6x6x30 at key 1
104 M5 nut 1
105 Hexagon pan head screws
M5x20L
1
106 Roller (top)
TT520440
1
107 6205 bearing 1
108 Wheel adjustment block
TT520110
1
109 6205 bearing 1
110 20 axis circlip 1
