CV Overview Chart
13.3. CV overview chart13.3. CV overview chart
13.3. CV overview chart13.3. CV overview chart
13.3. CV overview chart
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
Def.Def.
Def.Def.
Def.
1 Engine address Address of engine 1 – 127 3
2 Start voltage Sets the minimum speed of the engine 1 – 75 3
3 Acceleration This value multiplied by 0.869 is the time from stop to maximum speed 0 – 64 8
4 Deceleration This value multiplied by 0.869 is the time from maximum speed to stop 0 – 64 6
5 Maximum speed Maximum speed of engine 0 – 64 64
6 Medium speed Medium speed of engine 0 – 64 22
7 Version number Internal software version of LokSound decoder
8 Manufacturer’s ID Manufacturer’s ID & reset to factory defaults
by writing value 8 in this CV 151
13 Analogue mode F1-F8 Status of functions F1 to F8
in analogue mode 0-255 1
Bit Description Value
0F1 1
1F2 2
2F3 4
3F4 8
4F5 16
5F6 32
6F7 64
7 F8 128
14 Analogue mode FL, Status of functions
F9-F12 FL, F9 to F12 in analogue mode 0-255 3
Description Value
0 FL (f) 1
1 FL (r) 2
2 F9 (f) 4
3 F10 (f) 8
4 F11 16
5 F12 32
6 F9 (r) 64
7 F10 (r) 128
17 Extended engine address Long address of engine; CV17 contains byte with higher value (bit 6 0-128
and 9999, bit 6 and bit 7 must always be active), CV18 contains byte
with lower value (only active when function is switched on in CV 29).
19 Consist address Value 0 or 128 means: consist address deactivated
(additional in case of 1 - 127 consist address, normal direction
double traction) 129-255 consist address, reverse direction 0 – 255
CVCV
CVCV
CV
NameName
NameName
Name
DescriptionDescription
DescriptionDescription
Description
RangeRange
RangeRange
Range
Def.Def.
Def.Def.
Def.
29 Configuration register Bit Function value 0 - 55 4
0 Reverse travel direction (forward becomes reverse)
normal direction 0
reversed direction 1
1 speed steps (only for DCC mode)
14 speed steps 0
28 or 128 speed steps 2
2 analogue operation
analogue operation off 0
analogue operation on 4
4 selection of speed curve
speed curve through CV 2,5, 6 0
speed curve through CV 67 – 96 16
5 selection of engine address (only for DCC)
short addresses (CV 1) in DCC mode 0
long addresses (CV 17 + 18) in DCC mode 32
49 Extended configuration Activate support for brake sections
or switch off Back EMF control 0-128 19
Bit description value
0 load control off 0
load control activated in 1
1 DC motor PWM frequency
15 kHz pulse frequency 0
30 kHz pulse frequency 2
2 Märklin® delta mode
Delta mode off 0
Delta mode on 4
3 Märklin® second address
second address off 0
second address on 8
4 Automatic speed step detection
DCC speed step detection off 0
DCC speed step detection on 16
5 LGB function button mode
LGB mode off 0
LGB mode on 32
6 Zimo manual function
Zimo manual function off 0
Zimo manual function on 64
7 Loksound 2 behaviour on 0
LokSound 2 behaviour off 128
50 Analogue mode Selection of desired analogue mode 0-3 3
Bit description value
0 AC analogue mode
AC analogue mode off
AC analogue mode on 1
1 DC analogue mode
DC analogue mode off
DC analogue mode on 2
