7 Filling the storage room
Before filling the fuel store
Before filling, the conveyor and boiler must be fully
assembled and connected.
Also perform a visual inspection of the conveyor to
identify any damage or foreign objects.
CAUTION!
Never drive over the floor agitator
Floor agitator must be turning while filling
The floor agitator must be turning while the fuel store
is being filled. When the fuel store is empty, the floor
agitator's spring arms are extended. If the spring arms
are covered with fuel in this position, they will be
trapped and the floor agitator will no longer be able to
turn.
The rotation of the floor agitator is initiated from
the settings menu ( button, see 6.2 "
[Boiler]
function block – HACK") in the boiler overview window.
From this menu, set the [fill floor agitator] function to
[Yes]. This results in the boiler starting up for
30 minutes and the rotation of the floor agitator.
After filling, switch the boiler back to normal mode. In
doing so, reset the [fill floor agitator] function to [No]. If
this is not done, the boiler will automatically switch
back to normal mode after some time.
Start filling in the centre
Start filling the fuel store from the centre of the floor
agitator outward. If the floor agitator is filled from the
side, the rotating spring arm slices through the wood
chips and then speeds up in the still empty part of the
fuel store.
If the fuel store is filled through a hole from above, the
fuel must be fed onto the rotating floor agitator slowly.
The floor agitator can be damaged if a dumper load is
poured on "in one go" from a height of 3 m or possibly
even 6 m.
The maximum fill height of the fuel depends on the
fuel, or its weight:
• Pellets up to 2.0 m
• Wood chips up to 5.0 m
