1 General
The manual must be read thoroughly to avoid damage when handling and using the Cross chair.
is a warning triangle to indicate that special care should be taken.
(!) provides advice and tips worth considering
Anti-tips available as an accessory. At the correct setting they will prevent the wheelchair
from tipping backwards. We recommend all users to use the anti-tip devices, un-
less you are an experienced user with absolute control over your wheelchair.
The tool kit contains: 5 Allen keys: 6, 5, 5, 4 and 3 mm
3 Ring spanners: 13, 10 and 8 mm
1 Socket spanner: 24/19 mm
1 Phillips screwdriver
Cross is a manual, cross-folded, allround wheelchair with multiple functions and is intended for use both
outdoors and indoors. The seat is adjustable in height, angle and depth. The backrest is adjustable in
height, angle and contour. The footrests are adjustable in height, angle and depth.
Cross can be supplemented and adjusted if needs change. A large range of options and accessories are
available: Various types of backrest and legrest, fixing points for transport in mobility service buses, anti-
tips, various types of handrims and brakes etc.
Cross has the best prerequisites to create comfort, functionality and good manoeuvrability.
Crash test
Etac’s wheelchairs are tested in accordance with ISO 7176-19 and ISO 10542. These ISO standards specify
requirements for the design of the wheelchair’s restraint points, how the wheelchair and the user are
secured in the vehicle, and also describe how tests should be carried out and how the test results should
be interpreted. Etac’s wheelchairs are crash tested at the Technical Research Institute of Sweden. The tests
were carried out with normal settings on the wheelchairs (see manual for the respective wheelchair) and
with an UNWIN_WWR/ATF/K/R restraining device and an UNWIN_WWR/HD/ATF/K/R 3-point belt.
The cross-folded wheelchairs Cross, Twin and Transit were supplemented with securing points.
Seat widths: From 35 cm to 55 cm
Max. user weight: 125 kg.
Service life: The product is tested and fulfils the demands stated in EN 12183. The main product’s durabil-
ity and lifetime is at least five years when used in accordance with intended use, the safety instructions,
the reconditioning manual and instructions for use in the user manual. The main product consists of the
chassis for seat and back support. Additional parts/accessories are handled in accordance with the manual
and reconditioning manual. The actual lifetime can vary, depending on how much and how intensively
the product is being used, but a maximum of 10 years. If the product is intended for use after the service
life period specified by Etac, it is the responsibility of the product owner to ensure product functionality in
accordance with the manual and reconditioning instructions. If this cannot be ensured then the product
should be taken out of use.
The following methods of surface treatment have been used:
Lacquered surfaces=Polyester powder coating
Non-lacquered aluminium parts=Anodized coating
Non-lacquered steel surfaces=Galvanized
