31
Tools: 24 mm socket
spanner and adjustable
spanner.
The centre of balance can be
adjusted by changing the position
of the rear wheels.
- Move the axle shaft/rear
wheels forwards/backwards as
shown in point 6:8.
The brakes must also be
adjusted, see point 6:9.
Tools: 24 mm socket
spanner (10 mm spanner).
When the position of the rear
wheels is moved forwards the
wheelchair becomes much more
manoeuvrable, but the tendency
to tip backwards increases.
(!) The centre of balance is also
altered when the seat and/or
backrest angle is adjusted.
We recommend the use
of anti-tips.
Ensure that rear wheels
with quick release hubs
are mounted securely.
10 Driving technique, maneuvering
Cross
10:8 Adjusting the centre of balance
10:9 Changing the camber angle, Cross
The rear wheels are mounted with
a standard 2° camber angle.
You can change the camber angle
by changing the washers between
the axle shaft and the nut.
