Configure the Fixture 21
Separate Console Control and Video Server Control
The system contains a video control source in addition to a DMX console.
Example:
For each fixture:
Configure the Base module with DMX source and a unique address.
Set the Flex module to Compound mode.
Set the Pixel module to Independent mode, set the sACN or Art-Net source, and
assign a unique DMX address and universe.
The result: All fixtures have control for the 38 channels of Base module functions
and animations via DMX, and 148 channels of control for the Pixel module via
Ethernet from a video server.
Info Menu
Set the Time Information
Navigate:Main Menu → Info → Time Info
Parameter Value Description
Current Time XXXX (Hours)
Running time of the fixture from the last time that the
fixture was powered on, shown in hours (h). The
counter resets after the fixture is turned off.
Ttl Life Hrs XXXX (Hours) Total running time of the device, shown in hours (h).
Last Run Hrs XXXX (Hours)
Running time of the fixture from the last time that the
run time value was reset, shown in hours (h).
LEDHours XXXX(Hours)
Total running time of the fixture LEDs, shown in hours
(h).
Timer PIN Timer PIN XXX
You must enter the Timer PIN in order to access the Clr
Last Run menu item. The default Timer PIN is 038.
Clr Last Run
ON
OFF
This password-protected menu item resets the Last Run
Hrs value. You must enter the Timer PIN to access this
menu item.
Select ON to clear the value for the Last Run Hrs
parameter for the fixture.
LEDTime PIN LED Time PIN XXX
You must enter the LED Time PIN in order to access
the Clear LED Time menu item. The default LED Time
PIN is 038.
Clear LED Time
ON
OFF
This password-protected menu item resets the LED
Hours value. You must enter the LED Time PIN to
access this menu item.
Select ONto clear the value for the LED Hours
parameter.
View Fixture Errors
Navigate:Main Menu → Info → Error Info
Displays any current fixture errors. See
Error Codes on page29
for information about the errors.
