26 SolaPix 37 User Manual
Test Menu
Reset (Home) the Mechanical Positions on the Fixture
Navigate:Main Menu → Test → Home
Reset ("home") all features on the fixture, including, pan, tilt, colors, gobos, etc.
Test the Fixture
Navigate:Main Menu → Test → Self Test
Run a self-test program on the fixture. When you run the test, the display indicates "Running"
and the fixture automatically runs a self-test procedure, testing each of the functions. Press
[MODE/ESC] button to end the self-test and return the display to the previous menu.
Test an Individual Channel
Navigate:Main Menu → Test → Test Channel
Run a self-test program on individual channels. The default value is Control. Select a different
channel to run a self-test on that channel.
Manually Set an Individual Channel
Navigate:Main Menu → Test → Manual Ctrl.
Select an individual channel on the fixture and manually set the channel value. While in Manual
Control mode, all effects are canceled, the shutter opens, and the dimmer intensity is set to
100%.
Re-Calibrate an Individual Feature
Navigate:Main Menu → Test → Calibration
Please contact technical support at High End Systems, Inc. before using this parameter.
See
Contacting High End Systems on page1
.
You must enter the Calibration PIN in order to access the Calibration menu items. The default
Calibration PIN is 050.
Once you have accessed the Calibration menu, select an individual feature on the fixture and
manually calibrate it to a new "home" setting.
