22 SolaPix 37 User Manual
View DMX Values for Channels
Navigate:Main Menu → Info → DMX Value
View the DMX value of each of the fixture's channels (parameters of the fixture). Scroll to the
parameter that you want to view (Pan, Tilt, etc.) and view the value. The DMX value that you
view is the DMX value that displays on the main window of the UI until you select a different
DMX value to view.
View Fixture Head Temperature
Navigate:Main Menu → Info → Head Temp
Displays the current fixture temperature as read from the fixture head (near the CMYfilter).
View Power Temperature
Navigate:Main Menu → Info → Power Temp
Displays the current temperature as read from the power supply in the fixture base, which can
help you to determine if the power supply is overheating.
View Fan Speeds
Navigate:Main Menu → Info → Fan Speed
Displays the speeds of the fixture's fans (in RPM).
View Ethernet IP Address
Navigate:Main Menu → Info → Ethernet IP
Displays the Ethernet IP address for the fixture. You can modify this value in the Set menu.
See Access Service Settings on page24 .
View Software Version
Navigate:Main Menu → Info → Software Ver
Displays the software version for the fixture.
