Etel DSC Series Hardware Manual

ETEL Doc.- Hardware Manual # DSCDP / Ver G / 6/1/11
DSCDP Hardware Manual 9
Housed format
Rotary or linear motor for M2
Rotary or linear motor for M1
Communication with PC/CNC/
PLC (setup with ETT or ComET
software or 'host' commands)
Customers inputs / outputs
(CNC, PLC or joystick ...)
ETEL's DSCDP
15 slaves (max.)
+ DSMAX (or DSTEB)
Optional board
Auxiliary
power supply
Mains
Braking resistor
Rotary / linear incremental or
absolute (EnDat 2.1) analog
/ TTL encoder for motor M1
Rotary / linear incremental or
absolute (EnDat 2.1) analog
/ TTL encoder for motor M2
