ETEL Doc.- Hardware Manual # DSCDP / Ver G / 6/1/11
DSCDP Hardware Manual 21
2.3 Ordering information
Here is the ordering information describing the meaning of each digit present on the label of the DSCDP:
Remark: Not all the combinations are possible.
D S C D P321-111X-0 0 0
Family product:
DSCDP: 400VDC position controller
Encoder type:
1 = Analog (1Vptp) or TTL
3 = Analog (1Vptp) or absolute (EnDat 2.1) or TTL
Power output:
2 = 3 Arms / 7.5 Arms (1s)
3 = 3.5 Arms (for 10F rack) or 7 Arms (for 14F rack or housed
format) / 15 Arms (1s)
Assembly:
1 = Rack format with plate heat sink and frontplate of 10F
(available with power output 2 and 3, with relay option 1)
2 = Rack format with extruded heat sink and frontplate of 14F
(available with power output 3 and with relay option 1)
4 = Housed format (available with power output 2 and 3, with
relay option 3 or 4, with auxiliary supply input 2 and necessarily
with encoder type 3)
Relay option:
1 = Without relay (only for rack format assembly 1 and 2)
3 = With power stage relay (only for housed format assembly 4)
4 = With motor’s short-circuit relay AND power stage relay (only
for housed format assembly 4)
Auxiliary supply input:
1 = 120 - 340VDC
2 = 24 - 55VDC (only +24VDC for housed format assembly 4)
Standard option:
1 = Not UL recognized
2 = UL recognized
By default, the DSCDP is delivered without UL recognition
Hardware version
Customer modification
000 means ’standard product’
