5• TECHNICAL SPECIFICATIONS
H124DL H124DN H124DX
ENGINE
LOMBARDINI 1003 FOCS
Type Diesel 3 cylinders
Bore x stroke 75 x 77,6 mm
Cubic capacity 1028 cm
3
Fuel type Diesel or Biodiesel B30
Power (at 3000 rpm) 25 HP (18 kW)
Lubrication By oil pressure
Cooling 4 seasons coolant
Starter motor Electric 12 V
Alternator 30 A with regulator
Type of prefire sparkplug 12,5 V
Oil filter (engine) Cartridge 20 µm
Diesel filterl Cartridge 2 - 3 µm
Air filter Donaldson (with main cartridge + safety cartridge)
Speed of engine 2820 rpm ± 20
Oil sump capacity 2,3 l + 0,1 l for oil filter
Fuel tank capacity 19 litres
Hydraulic circuit capacity 33 litres
Air filter of hydraulic tank 3 µm
Oil filter of hydraulic circuit (cartdrige) 25 µm
Battery 12 V - 60 A
MOWER
Weight (empty) 815 kg 860 kg 895 kg
Cutting width 124 cm, 2 cutting devices, conter rotation indexed at 90 °
Blade drive Corner gear and shaft with elastic rings
Blade housing Mastershock Mastershock 8 mm with retractable side parts
Cutting height 9 heights / 1 transport position with adjustable stop
Blade clutch Electromagnetic with brake incorporated
Safety systems Conductor - box switches and for H124DN - H124DX on the deck
Ejection Central rear
Chassis design 2 tubular welded structures assembled by screws and bolts
Transmission 2 driving wheels with differential lock (for H124DN) 4 driving wheels without differential lock
Speeds Front : 0 to 16 km/h Rear : 0 to 14 km/h
Parking brake With disks mounted in the rear wheels
Tyres Front : 16 x 6,50 - 8 Rear : 23 x 10,5 - 12
Tyre pressure Front : 1,5 bar Rear : 1,2 bar
Front : 1, 9 bar (when equipped with a cabin or a front accessory)
Width Front : 1000 mm Rear : 934 mm
Distance between wheels 1400 mm
No cutted radius 1125 mm
Grassbox design Tubular structure
Grassbox capacity 580 litres
Grassbox discharge
Hydraulic on ground or high lift emptying to 1,80 meter max
.
Sound pressure at driver’s seat
(reference standards NF EN ISO 5395)
LpA = 90 dB (A)
KpA = 2,5 dB (A)
Seat vibration level (full body) Steering wheel vibration level (other appendages)
Directive 2006/42/EC
Reference standards :
NF EN ISO 5395, EN1032, EN1033
a
hw = 1,08 m/s²
K = 0,43 m/s²
a
hw = 1,29 m/s²
K = 0,65 m/s²
Directive 2002/44/EC
Reference standards :
ISO 2631-1, ISO 5349-1+2
1.4
a
wx 0,32 m/s²
1.4
a
wy 0,70 m/s²
a
wz 0,93 m/s²
Values to specify the daily exposure time
A (8) 0,93 m/s² A (8) 1,29 m/s²
