24-Port Web-Smart Ethernet Switch
User’s Manual
10
Installation and Placement Instructions
MOUNTED TO 19-INCH STANDARD RACK
Locate the accessories supplied in the product package. Use the
rackmount brackets and screws to install the switch into any EIA
19” standard rack.
Step 1: Attach the brackets to each side of the chassis.
Step 2: Apply the screws to each side and secure them tightly.
Step 3: Carefully position the switch into the rack.
Step 4: Align the brackets to the side holes on the rack and use rack
screws to secure the chassis with the rack.
Step 5: Proceed to the “Connecting to Power” section.
DESKTOP OR ANY FLAT SURFACE
The switch can sit on desktop or any flat surface with adequate
space and ventilation. If you want to place it onto a shelf, make
sure the shelf can withstand the weight of the switch.
Step 1: Simply put the switch on the desired place.
Step 2: Ensure the switch receives good ventilation.
Step 3: Proceed to the “Connecting to Power” section.
