KL8-3H-CAA6/KL8-3H-BAA6
In the waiting state， click “
Volume+
” Key，LCD blinking on the “PC” logo，indicating
that the system state into the power control settings，Without power control at this time。Then click
“
Volume+
” From the set state。
Power control settings in the state，“PC” logo will always be flashing，this time by “
PUMP1
”
PC1 key set to the state。Settings are completed，and then click“
Volume+
” From the set state。
20、Common Errors instructions：
Error flag Wrong reasons Error Handling
E1 A, temperature sensor or
disconnect missed.
B, temperature sensor short circuit
FF Not a good temperature sensor
E2 A, the flow sensor is not received or
disconnect B, short-circuit flow
sensor
Check the heater and the main electrical
box between the cable 5-pin plug or plug
is good.
EP A, circulating pump damage
B, non-flow through the internal
heater
A, circulating pump for damage.
B, whether or not to plug the filter inlet
4．Electric parameters
(1) Performance index：
Rated voltage： 220VAC/50Hz。 Maximum working current： 60A/220V
（110VAC/60Hz） （100A/110V）
Voltage-resistance： Isolative resistance ：>=200MΩ
1250V/1 minute without penetration。
Water resistance grade： IPX5。 Electric shock resistance： first grade
(2) Output loading index
Heater： AC220V/6KW. 。 Surf Water pump： AC220V/3 HP
（AC110V/3KW） （AC110V/2HP）
Circulation water pump： AC220V/1HP。 Blower： AC220V/1HP
Hot tub under water lamp： AC12V/10W。 Ozone： AC12V/15W
DC12V/10W
Radio： 1) Frequency Range： FM： 87.0~108.0MHz
2) Maximum Output Power： 20W
3) Speaker：8Ωdamp proof speaker
