10 PARTS LIST
Table 13, Spare parts
Pos
No.
Description Order No.
1
Mounting bracket
106-0085
2
Rear panel
x
Cable gland
106-0062
3
Air supply seal 8o mm
106-0059
4
Side panel incl. insulation
106-0103
5
Front panel, complete
Front panel lid incl. hinge
6
Flue pipe 80 mm
106-0082
Flue pipe gasket 80mm
106-0081
7
8
Flue box
106-0083
8-1
Flue box gasket 80mm
106-0120
8-2
Seal, flue pipe / jacket
106-0116
9
Siphon, complete
106-0529
Hose clip for condensate discharge
106-0573
Hose set for condensate discharge
106-0597
10
Burner control unit cover
10-1
Burner control unit (excl code key)
106-0565
Code key Ethos 36C
106-0567
Code key Ethos 54C
106-0622
Wiring harness, complete
106-0582
10-2
Control panel PCB
106-0572
10-3
Burner control housing, incl. labels
and jacket seal
11
Heat exchanger Ethos 36C
106-0525
Heat exchanger Ethos 54C
106-0527
Heat exchanger bleeder valve
106-0537
Heat exchanger spring clip
106-0134
Heat exchanger insulation disc
106-0074
11-1
High limit thermostat
106-0089
Adapter incl. high limit thermostat
106-0086
11-3
Measuring point cap incl. gasket
106-0060
12
Burner plate
Burner plate insulation
106-0575
Burner plate incl. insulating plate
106-0531
Burner plate M6 nuts
(set of 6 nuts)
106-0079
13
Burner Ethos 36C
106-0532
Burner Ethos 54C
106-0533
Burner gasket
106-0576
14 Ignition electrode 106-0534
Gasket ignition electrode 106-0080
Screws ignition electrode 106-0510
15
Gas pipe air-mixing box
x
Gas pipe gasket
106-0156
16
Fan
106-0537
Gasket, fan /gas-air mixing box
106-0577
Gasket, fan / gas-air duct
106-0578
17
Gas/air mixing box Ethos 36C
106-0562
Gas/air mixing box Ethos 54C
18
Insert Gas/air mixing Ethos 36C
106-0351
Insert Gas/air mixing Ethos 54C
106-0352
19
Gas-air duct
x
20
21
22
Pump, complete Ethos 36C
106-0540
Pump, complete Ethos 54C
106-0609
Pump motor Ethos 36C
Pump motor Ethos 54C
Pump O ring set
Pump stoppers incl. spring clip
Pump bleeder
Pump bleeder cap
106-0456
Three-way valve motor
23
DHW heat exchanger
106-0542
24
Gas valve
106-0543
Gas valve gasket
106-0156
25
DHW flow switch
106-0544
Flow switch gasket
26
DHW flow restrictor cock
106-0142
27
Manometer
106-0087
Manometer T-piece
106-0050
Drain cock
106-0126
28
CH return pipe
x
Flat gasket ¾”
106-0158
29
Lower gas pipe
x
Gas valve gasket ¾”
106-0156
30
Cold water inlet pipe
x
Cold water sensor
106-0433
31
Hot water outlet pipe,
x
Hot water pipe sensor
106-0433
32
CH supply pipe, in
x
Flat gasket ¾”
106-0158
33
Filter
106-0553
34
CH return pipe, in
x
CH return pipe O ring
106-0136
36
CH supply pipe to heat exchanger
x
NTC sensor 18mm
106-0434
CH supply pipe O ring Heat exch
106-0136
37
Return pipe elbow 90 gr
x
To Next Page
