ETQ DG4LN - Page 6

6
Technical specifications in English units
Item Model DG4LN DG6LN
Generator Type 2 electrode single-phase synchronous brushless
alternator
Excitation Self-excitation voltage
Voltage system Condenser compensation system
Frequency (Hz) 60 60
Rated power (kw) 3.5 5.5
Max. rated power (kW) 4.0 6.0
AC rated voltage (V) 120 / 240
DC rated output (V-A) 12-8.3
Speed (rpm) 3600 3600
Generator
Power factor (cos ϕ)
1.0
Engine type ETQ178FG ETQ186FG
Type Single-cylinder, vertical, 4-stroke, air-cooled, direct
injection
Continuous (HP) 5.9 8.85 Output
Maximum (HP) 6.6 9.85
Bore x Stroke (in.) 3.07 x 2.44 3.39 x2.76
Displacement (cu. in) 18.1 24.8
Lube-oil capacity (oz) 37.12 55.75
Diesel Engine
Fuel tank capacity (US gal) 3.57 3.96
Dry weight (lbs) 304 352
Set
Dimensions (L x W x H)
(in.)
33.3x20.9x27.8 36.2x20.9x27.8
