CHAPTER 1. TECHNICAL SPECIFICATIONS AND DATA
1-1 Technical specifications and data (in SI units)
Item Model DG4LN DG6LN
Generator Type 2 electrode single-phase synchronous brushless
alternator
Excitation Self-excitation voltage
Voltage system Condenser compensation system
Frequency (Hz) 60 60
Rated power (kW) 3.5 5.5
Max rated power (kW) 4.0 6.0
AC rated voltage (V) 120 / 240
DC rated output (V-A) 12-8.3
Speed (rpm) 3600 3600
Generator
Power factor (cos ϕ)
1.0
Engine type ETQ178FG ETQ186FG
Type Single-cylinder, vertical, 4-stroke, air-cooled, direct
injection
Continuous (kw) 4.40 6.6 Output
Maximum (kw) 4.92 7.34
Bore x Stroke (mm) 78 x 62 86 x 70
Displacement (cc) 296 406
Lube-oil capacity (L) 1.1 1.65
Diesel Engine
Fuel tank capacity (L) 15 15
Dry weight (kg) 138 160
Set
Dimensions (L x W x H)
(mm)
845 x 530 x 705 920 x 530 x 705
