Manual EKS Electronic-Key Adapter USB
2094485-05-07/19 Subject to technical modifications Page 13/34
4.2.2 Technical data for Electronic-Key adapter in G30 housing
Value
Unit
min.
typ.
max.
General parameters
Housing
Plastic (PVDF GF30, gray)
Degree of protection
IP65/IP67/IP69K in installed state
Ambient temperature
-20
+70/+100 *
°C
Mounting bore
Ø 22.5
mm
Power supply via USB
4.5
5
5.5
V
Current consumption
100
mA
Interface, data transfer
Interface to the PC
USB Full Speed (compatible with all USB versions)
Transfer protocol
3964R
Data transfer rate
9.6
kbaud
Data format
1 start bit, 8 data bits, 1 parity bit (even parity), 1 stop bit
USB interface connection
Type Mini-B socket
Cable length
3
m
LED indicator
Green: “Ready” (in operation)
Yellow: “Electronic-Key active” **
* This is not an ambient temperature for operation. It is valid for a time of no more than 3 minutes, e.g. for cleaning
purposes.
** The LED illuminates yellow if there is a functional Electronic-Key in the Electronic-Key adapter.
