ML530 Manual Version 1.0 Page 13 ©1999 Euphonix, Inc.
ML530 Mic-Line Interface Hookup Diagram – Standard Configuration
XLRFx12 to
EM38x1
Mic/Line Analog
Out
MADI out to
Studio Hub
1
AES/EBU Sync In
from Studio Hub
2
Control from 253i
Interface Pilot
AM713
MADI
OUT
4 4
3
Elco crimp pins and hoods for user
inputs are supplied in accessory
cable kits. Input cabling supplied by
customer
5, 6
