ML530 Manual Version 1.0 Page 9 ©1999 Euphonix, Inc.
Technical Specifications
Performance Specifications
Gain Range -12dB – 72dB in 0.5dB steps
Phantom Power +48V+/-2% (Switched per channel)
Maximum Input Level 41dB (Pad inserted, unity gain, @1KHz, @1% THD+N)
Differential Input Impedance 200Kohms (Hi Z, Pad off, +48V off)
200Kohms (Hi Z, Pad on, +48V off)
12.7Kohms (Hi Z, Pad on, +48V on)
12.7Kohms (Hi Z, Pad off, +48V on)
1.5Kohms (Lo Z, Pad off, +48V off)
1.5Kohms (Lo Z, Pad on, +48V off)
1.4Kohms (Lo Z, Pad on, +48V on)
1.4Kohms (Lo Z, Pad off, +48V on)
Maximum Output Level: 29dB (@1KHz, @1% THD+N)
Output Impedance: 100 ohms
Frequency Response: 10Hz - 90KHz (-0.5dB @ unity gain)
20Hz - 50KHz (-0.1dB @ unity gain)
10Hz - 60KHz (-0.5dB @ 30dB gain)
22Hz - 22KHz (-0.1dB @ 30dB gain)
10Hz - 90KHz (-0.5dB @ 66dB gain)
15Hz - 80KHz (-0.1dB @ 66dB gain)
Gain Accuracy: +/-0.15dB (@1KHz)
Distortion (THD+N): 0.0006%( @ 1KHz @ 0dB gain with
+13.5dB applied, 22KHz Filtered)
< 0.02% (20Hz – 20KHz @ 13.5dB 80KHz Filtered)
Equivalent Input noise, (EIN): -127dB (@66dB Gain, 22Hz – 22KHz Filtered,
Low Z mode, 150ohm source)
Common Mode Rejection (CMR): >50dB (10Hz – 30KHz)
Phase Linearity: +/-10 degrees (20Hz – 70KHz)
High Pass Filter: 80Hz 18dB/octave switched per channel
Phase Invert: 180 degrees switched per channel
