Getting Started (Cont.)
Removing the glass panel
• Before installing the heater, you have to remove the front glass panel so
that you can add the pebbles later.
• Place the flame effect heater glass-side down on a stable surface (table,
benchtop). Remove the screw on the right side of the heater (Fig. 2), which
holds the glass panel in place, then push the glass panel up and out of the
hanging scroll.
Fig. 2
• Carefully place the glass panel on a padded surface (material or
cardboard), to protect it from scratches. Keep the glass panel, and the
screw, in a safe place for reinstallation later.
Bracket installation
The wall bracket must be fitted horizontally and the power cord routed to the
bottom right of the heater.
• Using the large wall bracket as a template, mark the spot where you want to
position the heater (Fig. 3). Use a spirit level to ensure the bracket is level.
Fig. 3
(measurements in mm)
