Europlex Verifier 24 - RKD Base - Mounting Instructions

Fig. 6 - RKD Base
NOTE: Fig.6 shows the RKD base with Front
Cover and P.C.B. removed for
illustrativepurposes only - it is not
necessaryto remove these items when
mounting the RKD.
1-6
