APOLLO Windows XP Embedded Quickstart Unpacking and connecting up
© 2007 Eurotech Ltd Issue E 11
To unpack and connect up the APOLLO, follow these steps:
1 Remove the APOLLO CPU board from its packaging and place it on a static-free
work surface.
2 Plug a mouse into the green socket or one of the USB headers on the APOLLO.
3 Plug a keyboard into the purple socket or one of the USB headers on the APOLLO.
4 Plug a VGA monitor into the rear socket, as shown in the diagram on the preceding
page.
5 Plug the ATX Power Supply Unit (PSU) cable into the socket, as shown in the
diagram on the preceding page.
6 Connect up the breakout board, as shown in the diagram on the preceding page.
7 Fit the appropriate power lead to the PSU.
The power switch is located on the APOLLO breakout board.
