Configuration information
Once all the components have been imported to the component database, you can
open the configuration in Target Designer. The Standard XPe is installed as part of the
Target Designer Extensions package included on the Development Kit DVD. By
default, it is installed to the following folder:
C:\Arcom\APOLLO\TDExtensions\Configuration
To make it simple to save the configuration file once you’ve edited it, we
recommend that you copy the configuration file to your local hard disk and
open it from there, instead of from the DVD.
To view target device settings, follow these steps:
1 Open Target Designer.
2 Click on Settings, under StandardXPe.slx in Target Designer.
3 Click on Show, under Target Device Settings.
The target device settings shown suggest that images created using these settings
must be run from drive C:, with a boot partition size of 2048MB. These are the
settings used to create all the images shipped with this APOLLO Windows XP
Embedded Development Kit.
If you want to use a storage device with a boot partition size other than 2048MB,
change the Boot Partition Size settings under Target Device Settings.
If you want to use a boot drive other than the C: drive, you must change the target
device settings as appropriate. The settings you need to change may include the boot
drive, Windows folder, program files folder, documents and settings folder and the boot
ARC path.
To view information about any of these settings, click on (more info) next to
the name of the setting.
To create a new XP Embedded image with these target device settings, copy the new
image to the drive (as explained in
Transferring a new image to the APOLLO, page 37)
and then boot the system.
