EVAstream Mounting - Installation EVAstream Mounting - Installationwww.evaoptic.com12 13
2. EVAstream mounted with fixed position on the wall
l Mounting depth: 250 mm below water level.
l Mount the EVAstream horizontally on wall, in the middle of the poolwall.
l Please note that the fixed stainless steel parts must be connected to the ground
side view top view
3. EVAstream mounted on an installation niche
l Mounting depth: 250 mm below water level.
l Mount the EVAstream horizontally on wall, in the middle of the poolwall.
l Please note that the fixed stainless steel parts must be connected to the ground
side view top view
352mm 352mm
Ø265mm Ø265mm
74mm
240mm
200mm
250 mm below water level 250 mm below water level
420, 500 or 580mm
