EVAPCO ATC-E - ATC-E, ATW, Eco-ATC, Eco-ATW 3 & 3,6 M Wide Units

35
Operation and Maintenance Instructions
RECIRCULATING PUMP/
MOTOR ASSEMBLY
PUMP RISER PIPING
SUCTION HOOD & STRAINER
MAKE-UP VALVE
WITH ADJUSTABLE FLOAT
FRAMED AIR
INLET LOUVER
LOUVER RETAINER
BLEEDLINE AND VALVE
AIR INLET LOUVER MEDIA
COLD WATER BASIN
PUMP RISER PIPING
COIL CONNECTIONS
COIL
ACCESS DOOR
TEAO FAN MOTOR
SLIDING MOTOR BASE
FAN SCREEN
FAN CYLINDER
FAN
DRIFT ELIMINATORS
MECHANICAL EQUIPMENT
SUPPORT
WATER DISTRIBUTION
SPRAY BRANCH
FAN SCREEN SUPPORT
ATC-E, ATW, eco-ATC, eco-ATW 3 & 3,6 m Wide Units
FAN & COIL CASING SECTION
PAN SECTION
