EVAPCO ATC-E - ATC-E;Atwb;Eco-ATWB 4 X4 & 4 X6 Wide Units

34
AIR INLET LOUVER
STRAINER
MAKE-UP VALVE
WITH ADJUSTABLE FLOAT
RECIRCULATING PUMP/
MOTOR ASSEMBLY
PUMP RISER PIPING
FAN CYLINDER
F
A
N SCREEN
FAN
TEFC FAN MOTOR
WATER INLET
CONNECTION
DRIFT ELIMINATOR
COIL
PUMP RISER PIPING
BELT GUARD
COIL CONNECTIONS
FAN & COIL CASING SECTION
PAN SECTION
ATC-E/ATWB/eco-ATWB 4’x4’ & 4’x6’ Wide Units
