EVAPCO ATC-E - PMC-E;Eco-PMC 10 and 12 Wide Units

55
COIL CASING SECTION
RECIRCULATOR PUMP/
MOTOR ASSEMBLY
BLEED LINE
AND VAVLE
PUMP RISER PIPE
ACCESS DOOR
COLD WATER BASIN
SUCTION STRAINER
MAKE-UP VAVLE
WITH ADJUSTABLE FLOAT
FAN (PMWQ STANDARD
WITH SUPER LOW SOUND FAN)
ADJUSTABLE MOTOR BASE
TEFC FAN MOTOR
FAN BELT
FAN CYLINDER
DRIFT ELIMINATORS
C
OIL
DRIFT ELIMINATOR
S
UPPORT
W
A
TER DISTRIBUTION
S
PRAY BRANCH
COIL
C
ONNECTIONS
PUMP RISER PIPING
W
ATER DISTRIBUTION
SPRAY BRANCH SUPPORT
PAN SECTION
PMC-E/eco-PMC 10’ and 12’ Wide Units
