EVAPCO ATC-E - Page 56

56
TOP COIL/FAN SECTION
COIL
WATER DISTRIBUTION
BRANCH SUPPORT
F
AN SCREEN
TEFC FAN MOTOR
A
DJUSTABLE MOTOR BASE
F
AN CYLINDER
MECHANICAL EQUIPMENT
SUPPORT
SLIDING MOTOR BASE
FAN
WATER DISTRIBUTION
BRANCH
PUMP RISER PIPING
COIL CONNECTIONS
T
EFC FAN MOTOR
RECIRCULATING PUMP/
MOTOR ASSEMBLY
ACCESS DOOR
BLEED LINE
AND VAVLE
PUMP RISER PIPIING
MAKE-UP VALVE
WITH ADJUSTABLE FLOAT
COLD WATER BASIN
STRAINER
FILL SUPPORT
FILL
BOTTOM-PAN SECTION
PHC-S & L 12’ Wide-Single Side Air Inlet Units
