Evco EV3K11 User Manual

EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 35 of 72
Label Default Min. Max. U.M. Description
16 = Forced ventilation (NO)
17 = Filter pressure switch (NO)
100 = Room probe
101 = Supply probe
102 = External probe
103 = Discharge probe
104 = Water probe
105 = Compressor defrost probe
106 = Compressor discharge temperature probe
I04 103 -17 106 IN4 input function configuration; see parameter I03
I05 104 -17 106 IN5 input function configuration; see parameter I03
I06 16 -17 106 IN6 (EV3)/IN10 (EVD) input function configuration; see parameter I03
I07 9 -17 106 IN7 (EV3)/IN9 (EVD) input function configuration; see parameter I03
I08 18 -17 19
IN8 input function configuration
-17 = Filter pressure switch (NC)
-16 = Forced ventilation (NC)
-15 = External air damper closed limit switch (NC)
-14 = External air damper open limit switch (NC)
-13 = Dehumidifier request (NC)
-12 = Thermostat request (NC)
-11 = Heater thermal switch (NC)
-10 = Coil water antifreeze (NC)
-9 = Season change (NC)
-8 = remote ON-OFF (NC)
-7 = Compressor thermal switch (NC)
-6 = Low pressure (NC)
-5 = High pressure (NC)
-4 = Return flow switch (NC)
-3 = Supply flow switch (NC)
-2 = Return fan flow switch (NC)
-1 = Supply fan flow switch (NC)
0 = Disabled
1 = Supply fan flow switch (NO)
2 = Return fan flow switch (NO)
3 = Supply flow switch (NO)
4 = Return flow switch (NO)
5 = High pressure (NO)
6 = Low pressure (NO)
7 = Compressor thermal switch (NO)
8 = remote ON-OFF (NO)
9 = Season change (NO)
10 = Coil water antifreeze (NO)
11 = Heater thermal switch (NO)
12 = Thermostat request (NO)
13 = Dehumidifier request (NO)
14 = External air damper open limit switch (NO)
15 = External air damper closed limit switch (NO)
16 = Forced ventilation (NO)
17 = Filter pressure switch (NO)
18 = Supply tachometer (NO)
19 = Return tachometer (NO)

Evco EV3K11 Specifications

General

Brand	Evco
Model	EV3K11
Category	Controller
Language	English
