EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 36 of 72
Label Default Min. Max. U.M. Description
I09 19 -17 19 IN9 (EV3)/IN7 (EVD) input function configuration; see parameter I08
I10 8 -17 17
IN10 (EV3)/IN6 (EVD) input function configuration
-17 = Filter pressure switch (NC)
-16 = Forced ventilation (NC)
-15 = External air damper closed limit switch (NC)
-14 = External air damper open limit switch (NC)
-13 = Dehumidifier request (NC)
-12 = Thermostat request (NC)
-11 = Heater thermal switch (NC)
-10 = Coil water antifreeze (NC)
-9 = Season change (NC)
-8 = remote ON-OFF (NC)
-7 = Compressor thermal switch (NC)
-6 = Low pressure (NC)
-5 = High pressure (NC)
-4 = Return flow switch (NC)
-3 = Supply flow switch (NC)
-2 = Return fan flow switch (NC)
-1 = Supply fan flow switch (NC)
0 = Disabled
1 = Supply fan flow switch (NO)
2 = Return fan flow switch (NO)
3 = Supply flow switch (NO)
4 = Return flow switch (NO)
5 = High pressure (NO)
6 = Low pressure (NO)
7 = Compressor thermal switch (NO)
8 = remote ON-OFF (NO)
9 = Season change (NO)
10 = Coil water antifreeze (NO)
11 = Heater thermal switch (NO)
12 = Thermostat request (NO)
13 = Dehumidifier request (NO)
14 = External air damper open limit switch (NO)
15 = External air damper closed limit switch (NO)
16 = Forced ventilation (NO)
17 = Filter pressure switch (NO)
I11 0 -17 110 IN1 expansion input function configuration; see parameter I01
I12 0 -17 110 IN2 expansion input function configuration; see parameter I01
I13 0 -17 106 IN3 expansion input function configuration; see parameter I03
I14 0 -17 106 IN4 expansion input function configuration; see parameter I03
I15 0 -17 106 IN5 expansion input function configuration; see parameter I03
I16 0 -17 106 IN10 expansion input function configuration; see parameter I03
I17 0 -17 106 IN9 expansion input function configuration; see parameter I03
I18 0 -17 19 IN8 expansion input function configuration; see parameter I08
I19 0 -17 19 IN7 expansion input function configuration; see parameter I08
I20 0 -17 17 IN6 expansion input function configuration; see parameter I10
I21 0 0 1 Humidity probe on display
