Evco EV3K11 User Manual

EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 37 of 72
Label Default Min. Max. U.M. Description
0 = OFF
1 = ON
I22 0 0 1
Room temperature probe on display
1 = ON
I23 0 0 2
IN1 input type configuration
0 = NTC/Digital input
1 = 4-20 mA
2 = 0-10 V
I24 0 0 2 IN2 input type configuration; see parameter I23
I26 0 0 2 IN1 expansion input type configuration; see parameter I23
I27 0 0 2 IN2 expansion input type configuration; see parameter I23
I29 0 0 100 % Start of humidity probe/remote control scale [@4mA/0 V]
I30 100 0 100 % End of humidity probe/remote control scale [@20mA/10 V]
I31 0 0 5.000
ppm
Pa
Start of CO
2
probe/differential pressure scale [@4mA/0 V]
I32 2.000 0 5.000
ppm
Pa
End of CO
2
probe/differential pressure scale [@20mA/10 V]
I33 0,0 -12,7 12,7
°C-%-
ppm
Pa
IN1 analogue input offset
I34 0,0 -12,7 12,7
°C-%-
ppm
Pa
IN2 analogue input offset
I35 0,0 -12,7 12,7 °C IN3 analogue input offset
I36 0,0 -12,7 12,7 °C IN4 analogue input offset
I37 0,0 -12,7 12,7 °C IN5 analogue input offset
I38 0,0 -12,7 12,7 °C IN6 (EV3)/IN10 (EVD) analogue input offset
I39 0,0 -12,7 12,7 °C IN7 (EV3)/IN9 (EVD) analogue input offset
I40 0,0 -12,7 12,7
°C-%-
ppm
Pa
IN1 expansion analogue input offset
I41 0,0 -12,7 12,7
°C-%-
ppm
Pa
IN2 expansion analogue input offset
I42 0,0 -12,7 12,7 °C IN3 expansion analogue input offset
I43 0,0 -12,7 12,7 °C IN4 expansion analogue input offset
I44 0,0 -12,7 12,7 °C IN5 expansion analogue input offset
I45 0,0 -12,7 12,7 °C IN10 expansion analogue input offset
I46 0,0 -12,7 12,7 °C IN9 expansion analogue input offset
I47 5 -12 12
DO1 digital output function configuration
-12 = Alarm (NC)
-11 = Humidifier (NC)
