2
CODE
USED ON
MODEL
NO.
REQ.
PART
NUMBER
DESCRIPTION VENDOR
9 All 1 7995-3169 Booster Motor - 3000 RPM Fasco #7121-2842
10 All 1 7945A1351 Cover (Control Box)
11 All 1 7970-120 M ounting Plate (Ignition Module)
12 All 1 1474-0061 Ignition Module (Triple Try) RS #HS780-34NR-306A
13 All 1 7706-5251 Observation Plate (with gasket)
14 1 7706-3251 Gasket (Observation Plate)
15 All 1 7707-3261 Gas Valve (24V .5 Amp
1
/
2
”x
3
/
8
”) RS #7C5-C7F-026
16 All 1 ___________ Note: See chart for Burner Orifice Number
17 All 1 7945B5151 Valve Bracket
18 All 1 7656A5201 Panel (Coil Cavity 19
13
/
16
”)
19 All 1 1973-072/A Customer Envelope
20 All 1 7670-368P Thermostat (Adj. Ant.) RS #65A-943-462
21 All 1 7945-3011 Gasket Pkg. (Heat Exchanger)
22 056
070, 075
1 7956-5751
7975-5751
Heat Exchanger (with Gaskets)
Heat Exchanger (with Gaskets)
23 All 1 7975-3881 Remote Sensor
24 All 1 7681-3301 System Switch Carling #RC901-RB
25 All 1 7956-1121 Junction Box Cover
26 DGAM, DGAT
DLAS
1 2940A3541
7945-3551
Transformer (115-24V 40VA)
Transformer (115-24V 15VA)
JARD #TA151224-B11
27 All 1 7956-3671 Booster Relay RBM #134-40102-101D
28 All 1 7975-3281 Fan Switch (C-110˚ O-90˚) TOD #60T82 (200500)
29 056
070, 075
1 7945-3281
7970-3281
Limit Switch (O-140˚ C-110˚)
Limit Switch (O-145˚ C-115˚)
EX #402-679
EX #402-680
30 All 1 7975-3771 A/C Relay RBM 134-20103-301D
31 All 1 7970-5851/A Burner Assembly (Less Gas Valve -
Includes Codes 12, 13, 17)
32 All 1 1474-0521 Hot Surface Ignitor Norton #201N(W)
33 All 1 7970-179 Ignitor Shield
34 All 1 7945-1631 Mounting Plate (Burner)
35 All 2 7670-3451 Filter Retainer (Pk’d. 2)
36 All 1 7660-3401 Filter (19
3
/
8
x35
3
/
4
x
1
/
4
)
37 DGAM
DGAT, DLAS
1
1
7975-1561
7956-5231
Panel (Upper)
Panel (Upper)
38 DGAM, DGAT
DLAS
1 7956-1571
7956-1631
Panel (Lower)
Panel (Lower)
BURNER ORIFICE CHART (Code 16)
MODEL 056 070 075
Nat. 9951-1281 9951-1491 9951-1541
LP 9951-0821 9951-0931 9951-0961
BLOWER PARTS
CODE SERIES DESCRIPTION
056, 070 & 075 095
39 DGAT, DLAS
DGAM
Motor
Motor
7966-311P
1468-2209
WEST #322P289 1468-2129
1468-2209
WEST #322P890
40 Scroll 7966A530 7966A530
41 Motor Mount
(3/Pkg.)
7670-3551 7670-3551
42 Connector Plug 7680-348 7680-348
43 Motor Clamp 7670-5391 7670-6391
44 Run Capacitor None 1499-4461
7.5 Mfd. 370V.
45 Blower Wheel
(105/8Dia.x71/8x
1/2)
1472-2751 TORIN #CM1020-704-5
LAU #027855-10
MORR #03-42001-0
1472-2751 TORIN #CM1020-704-5
LAU #027855-10
MORR #03-42001-0
NOTE: All parts with three digit suffix numbers are “Special Order” Parts. These parts are subject to factory availability and require extra
time for delivery.
LITHO IN U.S.A.
3110 North Mead
P.O. Box 19014
Wichita, KS 67204-9014
Evcon Industries, Inc.
1973-098 Rev. 1 (12/94).
