5 Burner Gas Grill
OWNER’S MANUAL
ASSEMBLY AND OPERATING IN STRUC TIONS
WARNING
HAZARDOUS EXPLOSION MAY RESULT IF THESE
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ
AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH
OR PROPERTY DAMAGE.
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS WITH
THE GRILL OWNER FOR FUTURE
REFERENCE .
SAVE THIS MANUAL FOR FUTURE REFERENCE
Model GAS1566AS

Table of Contents

Questions and Answers

  • Q
    qhouseAug 15, 2025
    How to fix Even Embers GAS1566AS burner that will not light?
    • K
      Karl CowanAug 15, 2025
      If the burner on your Even Embers Grill won't light, start by checking that the LP gas tank valve is open and securely attached. If the tank is low or empty, replace or refill it. Also, inspect for any gas leaks, following the “Leak Testing” instructions. Obstructions in gas flow can also prevent lighting, so clean the burner assembly and check for bent or kinked hoses. Ensure the burner is properly seated and that the venturi is clear of spider webs or insect nests. Clogged burner ports should be cleaned, and a dead battery should be replaced. Finally, cooking residue on wires or electrodes should be cleaned with rubbing alcohol, and any wet components should be wiped dry.
  • M
    Michael VillegasAug 17, 2025
    Why is my Even Embers GAS1566AS not getting hot enough?
    • M
      Melissa RogersAug 18, 2025
      If your Even Embers Grill isn't getting hot enough, the first thing to check is whether you are out of gas. If so, replace or refill the LP gas tank. If that's not the issue, a flow limiting device may have been activated. Try a mini reset by turning the control knobs and LP gas tank valve to “OFF”, waiting one minute, and then relighting the grill per the “Lighting Instructions”. If the flames are still too low, perform a full reset: Turn everything off, disconnect the regulator from the propane tank, inspect the LP cylinder rubber seal, wait one minute, reconnect the regulator, perform “Leak Testing” on all connections, and then light the grill per the “Lighting Instructions”.
  • C
    colemanalexanderAug 21, 2025
    What to do if my Even Embers GAS1566AS Grill has a flare-up?
    • S
      Sarah RichardsAug 21, 2025
      Flare-ups on your Even Embers Grill can occur due to grease buildup. Clean all grill parts according to the “Proper Care and Maintenance” instructions. Excess fat in meat is another common cause, so trim fat from meat before grilling. Finally, excessive cooking temperature can also lead to flare-ups; adjust the cooking temperature to a lower setting.
  • J
    Julie WallaceAug 25, 2025
    What to do if my Even Embers GAS1566AS has a grease fire?
    • E
      Edward DavisAug 25, 2025
      A grease fire on your Even Embers Grill is often caused by grease trapped by food buildup around the burner system. If this happens: 1. Turn control knobs and the LP gas tank valve to the “OFF” position. 2. Leave the lid either open or closed and allow the fire to burn out. If necessary, use a BC type fire extinguisher, baking soda, sand, or dirt to smother the fire. 3. After the grill cools down, remove and clean all parts following the “Proper Care and Maintenance” instructions.
  • D
    Dennis ShermanAug 27, 2025
    Why is the flame on my Even Embers GAS1566AS Grill yellow or orange?
    • C
      Cynthia NunezAug 28, 2025
      If the flame on your Even Embers Grill is yellow or orange, it could be due to a few reasons. If it's a new burner, it may have residual manufacturing oils; burn the grill for 15 minutes on “HIGH” with the lid closed. Spider webs or insect nests in the venturi can also cause this issue, so clean the venturi and burner assembly. Food residue or grease buildup can also affect the flame, so clean the burner assembly. Lastly, poor alignment of the valve to the burner venturi can be the culprit; ensure the burner venturi is properly engaged with the valve.
  • P
    Pamela BaileyAug 31, 2025
    Why does my Even Embers GAS1566AS Grill have an irregular flame pattern?
    • K
      Kyle WrightAug 31, 2025
      An irregular flame pattern on your Even Embers Grill, where the flame does not run the full length of the burner, is often due to clogged or blocked burner ports. Clean the burner ports to resolve this. Another potential cause is that the air shutter on the burner needs adjustment. Refer to the “Burner Adjustment” section for instructions.
  • D
    David BarrySep 3, 2025
    Why does the flame keep blowing out on my Even Embers GAS1566AS Grill?
    • S
      Stacey TorresSep 3, 2025
      If the flame on your Even Embers Grill blows out, it could be due to high or gusting winds; avoid using the grill in such conditions. Another reason could be that you're low on LP gas; replace or refill the LP gas tank. Obstructions in the burner holes can also cause this; refer to the “Burner Assembly/Maintenance” instructions. Lastly, a tripped flow limiting device might be the issue; refer to the “Regulator Resetting Procedure”.
  • S
    Sean ThomasSep 7, 2025
    Why is my Even Embers GAS1566AS having flashback or melting knobs?
    • R
      robinsonjakeSep 7, 2025
      Flashback (fire in burner tubes) or melting knobs on your Even Embers Grill usually indicates that the burner and/or burner tubes are blocked. To resolve this, clean the burners and/or burner assembly.
  • Z
    zjonesSep 12, 2025
    Why is the inside of the lid peeling on my Even Embers GAS1566AS Grill?
    • A
      Adam MartinSep 12, 2025
      If the inside of the lid on your Even Embers Grill is peeling, resembling paint peeling, it's likely due to baked-on grease buildup that has turned into carbon and is flaking off. To fix this, clean the grill thoroughly following the “Proper Care and Maintenance” instructions.

Summary

Important Safety Warnings

If You Smell Gas

Procedure to follow if gas odor is detected.

General Safety Precautions

Key warnings and dangers for safe grill operation.

California Proposition 65 Warning

Warning about chemicals known to cause birth defects or reproductive harm.

General Warnings

LP Gas Cylinder (Tank) Specifications and Installation

LP Gas Cylinder Safety

Warnings and dangers related to LP gas cylinders.

Filling the LP Gas Cylinder

Safe procedures and warnings for refilling LP gas tanks.

Hose & Regulator Specifications and Installation

LP Gas Cylinder Seal Inspection

How to inspect the LP gas cylinder's rubber seal.

Installing the LP Gas Cylinder

Steps for correctly installing the LP gas cylinder onto the grill.

Hose and Regulator Details

Features and specifications of the grill's hose and regulator.

Connecting Hose and Regulator

Step-by-step guide for connecting the hose and regulator to the cylinder.

Regulator Resetting Procedure

Steps to reset the regulator's flow limiting device.

Leak Testing

Leak Testing Procedure

Detailed instructions for performing a leak test on gas connections.

Pre-Start and Lighting Instructions

Pre-Start Check List

Essential checks before operating the grill.

Gas Lighting Instructions

General instructions for lighting the grill's burners.

Lighting the Main Burners

Instructions for igniting the main burners.

Match Lighting the Main Burner

Procedure for lighting main burners using a match.

Lighting the Side Burner

Instructions for igniting the side burner.

Match Lighting the Side Burner

Procedure for lighting the side burner using a match.

Operating the Grill

Breaking In Your Grill

Initial steps to prepare the grill for first use.

Preheating the Grill

Recommended procedure for preheating before cooking.

Controlling Flare-Ups and Grease Fires

Guidance on managing flare-ups and grease fires.

Minimizing Flare-Ups

Techniques to reduce flare-ups during cooking.

Indirect Cooking Method

Explanation of the indirect cooking technique.

Using Other Grill Features

Rotisserie Cooking

Information on using a rotisserie attachment with the grill.

Turning Off the Grill

Correct procedure for shutting down the grill safely.

The Side Burner

Operation and usage guidelines for the side burner.

Proper Care and Maintenance

Cleaning the Grill Interior

Instructions for cleaning the inside of the grill.

Maintaining the Grill Exterior

Guidelines for cleaning and protecting the grill's exterior.

Burner Cleaning and Maintenance

Procedures for cleaning and maintaining the grill's burners.

Burner Assembly;Maintenance

Transporting, Storage, and Griddle Use

Transporting and Storage

Guidelines for safely moving and storing the grill.

How to Use the Griddle

Instructions for using the stainless steel griddle accessory.

Troubleshooting

Grill Cooking Tips

Cleanliness Guidelines

Best practices for hygiene when handling food.

Grilling to Proper Temperature

Recommended internal temperatures for various foods.

Helpful Hints

Additional tips for cooking and food safety.

Assembly Instructions

Warranty Information

Even Embers GAS1566AS Specifications

General IconGeneral
TypeGas Grill
Fuel TypePropane
MaterialStainless Steel
Grate MaterialPorcelain-Coated Cast Iron
Secondary Cooking Area170 square inches
Ignition TypeElectronic
