40 41
CLICK!
Turn the base over as
shown.
Pull the load leg out
as shown. On top of load
leg is an indicator. When
it’s fully rotated, the
indicator will change to
green.
Turn base over and place
base on the seat as shown.
Note: After the base is
installed.(p.52) place the
carrier in the base. Then
extend the load leg into
position by following steps
5 and 6.
SafeZone
TM
Load Leg (cont.)
2
3
1
4
To extend load leg, pull leg
down until it reaches the floor
and the indicator turns green.
If it does not rest flat on the
floor, push button and lower
leg to floor to extend further.
Indicator should turn green.
ALWAYS CHECK to make
sure when the leg rests on the
vehicle floor that it does not
lift the base off the seat.
Leg must always lock into one
of the open positions before
using. If leg does not lie flat
on the floor, move to another
seating location or do not use
the load leg in your vehicle.
CLICK!
5
6
SafeZone
TM
Load Leg (cont.)
