Evenflo NurtureMax - Child Restraint Features (Convenience Base); NurtureMax Convenience Base (Bottom View); Removing and Storing Lower Anchor Connectors; Connector Removal Steps

17
Child Restraint Features
NurtureMax Convenience Base (Bottom)
Lower Anchor
Connector Assembly
Vehicle Seat Belt Path /
Lower Anchor Connector
Strap Openings
Lower Anchor
Connector Storage
Removing and Storing
Lower Anchor Connectors
1
When the lower anchor connector system is not
in use, you MUST securely store it on the base
as shown above using the storage bars on the
underside of the base. A loose lower anchor
connector strap and hook may injure your child.
2
3
Press the tab and
twist, then remove the
hook from the anchor.
Press the adjuster
release button to
loosen lower anchor
connector assembly.
