36 37
1.
Convert child restraint to booster seat.
See “Converting into a Booster Seat,” p. 38.
2.
Secure booster seat to the vehicle seat.
a
Make sure the bottom and back of the booster seat
are touching vehicle seat and back.
aLevel the booster seat (Canadian models only),
p. 42.
3. Place the child in the booster seat.
Make sure the child’s back and bottom are flat against
the back and bottom surfaces of the booster seat.
4. Adjust headrest for proper shoulder
belt fit.
The top of the child’s ears are at, or below, the child
restraint headrest and the shoulder belt MUST cross
midway between the child’s shoulder and neck,
as shown at left.
5.
Secure child and booster seat to vehicle
seat.
✔Stretch the lap/shoulder belt across the child and
fasten the buckle. Make certain the shoulder belt is
threaded through the shoulder belt guide on the
headrest.
✔Confirm belt routing p. 42.
6. Check your work.
The shoulder belt
MUST cross midway
between child’s
shoulder and neck.
The shoulder belt MUST
pass through shoulder
belt guide and under the
headrest.
The lap belt is
stretched low and
snug across the
child’s hips and
routed under the
lap belt guides.
IMPORTANT
Always secure the booster seat with the LATCH
connectors or vehicle seat belt when not occupied.
An unsecured booster seat can fly into and
injure other occupants in the event of a crash.
Using as a Booster Seat
Child Requirements
Weight: 18 – 49.8 kg (40 – 110 lbs)
Height: 110 – 145 cm (43.3 – 57 in.)
tall AND the tops of the child’s ears are
at, or below, the child restraint headrest.
Age: At least four years old
This line MUST be level
to the ground
(Canadian
Models Only)
.
Using as a Booster Seat
Booster Installation Checklist
WARNING
•
The shoulder belt MUST NOT cross the child’s neck
or fall
off the child’s shoulder. If you can not adjust
the shoulder belt to properly lay midway between
the child’s shoulder and neck AND at or above the
shoulder, try another seating location, or do not use
the booster seat.
