Visual Glossary Visual Glossary
Your vehicle components may be significantly different than
pictured. Consult your owner’s manual to help you identify your
vehicle components.
Back Seat
Belt Buckles
Center Lap
Belt
Tether Anchors
Forward-facing
ONLY
Back Seat
Belt
Retractor
Seat Crease
Lap/
Shoulder
Belt
Vehicle Lower
Anchor Bars
Fold-down Armrest
Consult your vehicle’s
owners manual.
Rear
Headrests
IMPORTANT: If your vehicle has side air bags, please refer to the
warnings on page 2.
Front Seat
Retractor
120
4
A I R B A
G
20
30
10
Front Seat Lap
and Shoulder Belts
Front
Headrests
Consult your vehicle
owner’s manual to determine
proper placement of child restraint
in your vehicle and familiarize
yourself with your vehicle’s
components.
IMPORTANT
IMPORTANT
NO coloque el asiento infantil orientado
hacia atrás en el asiento delantero con
bolsa de aire.
Puede causar MUERTE o LESIONES GRAVES.
El asiento trasero es el lugar más seguro para
los niños de 12 años de edad y menores.
5-pt Harness
Straps
Chest Clip
Harness
Release
Button
Headrest
Shoulder Belt
Guide
Buckle
Harness
Adjust Strap
Tether Strap and Hook
(Shown fastened to
storage clip)
Headrest
Instructions
Upper Belt Path
Upper Belt Path
SureLatch
Connector*
SureLatch
Connector*
Model Number &
Date of Manufacture
Splitter Plate
Lower Belt
Path Guide*
Lower Belt
Path Guide*
LATCH Guide
LATCH Guide
Tether Strap
Adjuster
(Push Button Release)
OR
Tether Strap
Adjuster
(Lever Release)
Cup Holder*
Cup Holder*
* Not available on all models.* Not available on all models.
