40
E
F
F
C
When the LATCH system is not in use, you MUST
securely store it in the area provided in the bottom of
the base E.
Route the harness strap through the belt path on top of
the base then attach the hooks to the slots F located on
each side of the storage area beneath the base.
A loose LATCH harness and hook may injure your child.
Removing the LATCH System
1
2
3
Press the adjuster release
button A to loosen harness
strap.
A
To remove the hook B,
press the tab C and
twist, then remove from
anchor D.
B
D
To Next Page
