Assembly, Operation & Maintenance Instructions
PARTS LIST: HBCE2BUS
PART NAME
QTY
1 Foot Front 1
2 Hex Bolt M6x0.5in (12mm) 16
3 Leg Upper Right Front 1
4 Foot Rear 1
5 Leg Upper Right Rear 1
6 Chassis Right Hand Side Panel 1
7 Pole Assembly Support 2
8 Hex Bolt M8x0.4in (10mm) 4
9 Plug Recess 1
10 Plug recess Bracket 1
11 Retractable Power Cord Assembly 1
12 Power Cord Assembly Cover 1
13 Chassis Rear Panel 1
14 Chassis Top Plate Assembly 1
15 Element Spring 1
16 Grill Support Long 4
17 Inner Pole Assembly Right 1
18 Inner Chassis 1
19 Pole Flange 2
20 Right Open Grill 1
21 Lid 1
22 Rotisserie Fork 4
23 Rotisserie Rod 1
24 Lid Handle 1
25 Inner Pole Assembly Left 1
26 Left Open Grill 1
27 Outer Pole Assembly 2
28 Charcoal Grid 1
29 Charcoal Chamber 1
30 Element Assembly 1
31 Top Panel Covers 2
32 Element Support 2
33 Storage Door 1
34 Element Heat Shield 1
35 Grill Support Short 8
36 Element Bowl 1
37 Barbeque Handle 2
38 Chassis Left Hand Side Panel 1
39 Element Bowl Support 1
40 Fork & Rod Storage Box 1
41 Door Magnet 2
42 Chassis Front Panel 1
43 Chassis Bottom Panel 1
44 Castor Leg Rear 1
45 Thermostat Mount 1
To Next Page
