INSTALLATION
CABINET DIMENSIONS & VENTILATION REQUIREMENTS
VENTILATING OPENINGS
When cooking is finished or in pause state or in waiting state, if the oven's center temperature is over 75 degree, the
cooling fan will continue working for 15 minutes. Or when the oven's center temperature becomes lower than 75
degree, the cooling fan will stop in advance.
SECURING THE OVEN TO THE CABINET
1. Fit oven into the cabinet recess.
2. Open the oven door.
3. Secure the oven to the kitchen cabinet with two distance holders "A"
which fit the holes in the oven frame and fit the two screws "B".
Ventilating openings
555
20
595
595
560
570
min.
560
606
600
80
250
100
