DESIGNED TO PERFECTION
APPLIANCE DETAILS
ELECTRICAL DETAILS UFGS69:
Rated Voltage: 220-240V / 50-60 Hz
Max Rated Inputs: 3000W.
This information can be found on the rating plate (data label) affixed to
the rear of the appliance.
GAS
CATEGORY
I3+(28-30/37) I3B/P(30) I3B/P(50) I2H I2L
TYPES OF GAS
Butane/Propane Butane Butane Natural Gas Natural Gas
GAS PRESSURE
G30:29mbar,
G31:37mbar
G30:29mbar G30:50mbar G20:20mbar G25:25mbar
TOTAL HEAT
INPUT (Qn)
G30:7.5kw,545.8g/h
G31:7.5kw,536g/h
7.5kw,545.8g/h 7.5kw,545.8g/h 7.5kw,508.2g/h 7.5kw,591.7g/h
INJECTOR SIZE
(mm)
A:0.65 B:0.65
C:0.85 D:0.5
A:0.65 B:0.65
C:0.85 D:0.53
A:0.58 B:0.58
C:0.75 D:0.43
A:0.97 B:0.97
C:1.3 D:0.72
A:0.95 B:0.95
C:1.22 D:0.7
COUNTRY OF
DESTINATION
BE,CH,CZ,ES,FR,GB,GR,
HU,NL,NO,PT,SE,SI
DK,FI,GB,GR,HU,ML,
NO,PT,SE,SI
AT,DE AT,CH,CZ,DK,ES,FI,GB,
GR,IE,IS,IT,PT,SE,SI,
SK,DE,LU,GE,FR
NL
APPLIANCE
TYPE A1
A1
SIZES:
The appliance is supplied with one wire shelf and one oven tray. Each shelf and tray comes with a built-in
safety feature to help minimise them being accidentally pulled fully out. This comes in the way as a “step”,
positioned at the rear of the shelf or tray.
To fit them into the oven, push the shelf or tray part way into the oven at an angle, then fully insert. To
remove, repeat the process in reverse.
ATTENTION: if the cooker rest on a base, take the measures necessary to prevent the cooker from sliding
along the support base.
ATTENTION: The unit becomes hot during use. Do not touch the heating elements inside the oven.
ATTENTION: The accessible parts can become hot during use. Keep children away from the appliance.
ATTENTION: Do not use harsh abrasive cleaning products or metal spatulas with sharp edges to clean the
oven door’s glass since this could scratch the surface and the glass could break.
OVEN RATING
Top element 950W
Bottom element 1100W
Grilling element 2000W
Rear turbo element 2000W
Fan motor 33W
Lamp 25W
Relevant Sizes: DEPTH (mm) WIDTH (mm) HEIGHT (mm)
External Oven size 600 600 900 (885-915)
4
