ECOR960 4F2 / 8F2 / 16F2
11
4. Screw the HDD to the bottom of the DVR using supplied screws. (8CH DVR)
Figure 2-3
5. Connect the internal SATA cable to the SATA port of the HDD.
Figure 2-4
6. Connect the internal power cable to the HDD.
Figure 2-5
7. Screw back the hosing to the DVR.
8. Format the HDD after the installation is completed.
