81
Drainage Systems
9.6 Cockpit & Water System Drains
Baitwell
The baitwell in the bait station is drained by gravity
to a thru-hull tting in the hull side. The baitwell
overow drains to the bait station drain system.
Cup Holder Drains
All cup holders in the helm and cockpit areas drain
by gravity to the cockpit sole.
Console Seat Storage Compartment/Cooler
The storage compartment/cooler below the for-
ward console seat is drained overboard by gravity
through a tting in the hull.
Rope Locker Drain
The rope locker drains overboard through a small
drain hole in the bottom of the locker. It is im-
portant to inspect the drain frequently to remove
any accumulated debris.
Bow Storage Compartment/Cooler & Rod Locker
Baitwell
Console Seat Compartment/Cooler
Rope Locker Drain
To Next Page
