TR3200E Tally Data Router
Revision 1.0 Page - 1
1 OVERVIEW
The TR-3200E Tally router is used in conjunction with MAGNUM-TALLY. It receives tally inputs from a
device, such as a vision mixer, and provides this information to MAGNUM-TALLY which then
processes the information. The information can then be used by MAGNUM-TALLY to provide tally
information to cameras, Under Monitor Displays (UMDs), switchers, etc.
The TR-3200E Tally router provides up to 64 tally inputs and up to 32 tally outputs.
Features:
• 64 tally inputs
• 32 tally outputs
• Housed in a 1RU frame
Figure 1-1: Front Panel View
Figure 1-2: Rear Panel View
