6
40"
16"
Optional
Hearth
Extension
Fireplace
Openin
Top Stand-
Off Spacer
(on appliance)
Top of Appliance
Finished Wall
Header
Non-Combustible
Material
3" Min.
(shaded area)
Shown with hood
Installed (required
on EWVF36)
Ceiling clearance: The ceiling must be at
(Figure 2 ).
Noncombustible material: Noncombustible
materials, such as slate and marble, must be
at least 1/2" thick and may be used without
they do not obstruct vent openings for heat
circulating models.
RECOMMENDATION: Use high temperature
finish material for the mantels.
Clearances
Ensure the minimum clearances shown in
Figures 2 through 4
right clearances are determined when facing
Follow these instructions carefully to ensure safe
Sidewall clearances:
-
bustible wall (Figure 2).
Figure 2
Not to Scale
Figure 1
Combustible Wall Clearance
Above Appliance (all models)
Figure 3
CAUTION
Do not install in the vicinity where
gasoline or other flammable liquids
may be stored. The Vent-Free fire-
box must be kept clear and free from
these combustible materials.
WARNING
Do not use a blower insert, heat
exchanger insert or other acces-
sory not approved for use with this
appliance.
WARNING
Do not install these built-in Vent-
Free fireboxes in sleeping quarters,
or in recreational vehicles.
WARNINGS
Do not install these appliances:
•
Where curtains, furniture, cloth-
ing or other flammable objects
are less than 42" from the front
of the Vent-Free room heater.
•
In high traffic areas.
•
In windy or drafty areas.
LOCATION OF FIREBOX
Carefully select the best location for installation
• Clearance to side wall, ceiling, woodwork
and windows.
•
registers for forced air furnaces/air condi-
tioners, windows or doors.
• -
tion and combustion air.
•
or bathroom.
•
and away from furniture and draperies due
combustion and ventilation air.
-
tion. See Figure 1 for location suggestions.
