FIREBOX FINISHES
paneling or warm brick facings.
Raised Hearth Extension
(combustibles allowed.
No carpet or vinyl)
Combustible Platform
SIDE VIEW
Firebox Floor
Combustible Wall
Figure 23 - Raised Hearth Extension
Non-Combustible Wall
(see Figure 4)
Fireplace Opening
* From Base to Bottom of
Firebox Opening (floor)
5-3/4" Max.*
Base
and wall surrounds to prevent air intrusion. Use noncombustible caulking
material only to seal the black metal facing to the surround material on
Figures 3 and 23.
Raised Hearth Extension
Figure 23.
