14
Step 9.
EWFBK100Kits-InstallalocallysourcedON/OFFwallswitch
in a convenient location on a wall, near the fireplace.
EWFBK200Kits-Installthekit-providedvariablespeedcontrol
(rheostat) in a convenient location on a wall, near the fireplace.
Step 10.
Model EWVF36:
Reinstall the blower access panel that was removed on Step 1 (see
Figure 15).
Step 8. Ensure that power supply wires are NOT "live" before making
these connections). Install J-Box Cover Plate as follows:
protection to the wires and prevents strain against connections
Figure 14. Install the cover
Figure 22.
NOTE: Wire connections should be positioned inside of the ap-
pliance.
*
non-metallic sheath.
Cabinet Base
Figure 19
Figure 20
Figure 21
Loose knot in power
cord to take up slack
Locating Tabs
Bend Locating Tabs Over
(into notches)
Use screw provided and
secure in place as shown
The notched side of
cover plates goes inside
firebox panel
Screw
Cover Plate
Right Side Panel of Firebox
Figure 22 - Installing J-box Cover Plate - All Models
J-Box opening
on appliance
Step 6.
side of appliance.
Step 7.
knock-out (see Figure 16).
Firebox
floor
To Next Page
