Everwell FCAC Series - Page 12

R410A 60Hz EER 2.36 Series Service Manual
No. Part Name Quantity No. Part Name Quantity
1
Chassis foam assembly
1 13.2
Display film
1
2
Rear cover
1 13.3 Display board mounting box 1
3
Chassis assembly
1 14
Air inlet grille
1
4
Indoor PCB assembly
1 15
Top Cover assembly
1
4.1
E-part box
1 16
Supporting board
1
4.2
Indoor PCB
1 17.1
Drip tray foam
1
4.3
Fan capacitor
1 17.2
Louver connecting rod fixed structure class1
1
4.4
Transformer
1 17.3
Louver connecting rod fixed structure class2
1
4.5
Temperature sensors indoor )
1 17.4
Driving lever for louver
1
4.6
Terminal
1 17.5
Louver holder
1
5
E-part box cover
1 17.6
Guard vane
9
6
Left cover
1 18
Right separating board
1
7
Hoisting pate
2 19
Right cover
1
8
Lelf separating board
1 20
Evaporator component
1
9
Weld assembly for intermediate
transverse girder
1 20.1
Evaporator assembly
1
10
Pipe clamp
1 20.2
Evaporator output tube assembly
1
11.1
Centrifugal fan blade
2 20.3 Evaporator input tube assembly 1
11.2
Upper volute
2 20.4
Under the right mounting plate of the
evaporator
1
11.3
Lower volute
2 20.5
Under the left mounting plate of the
evaporator
1
12.1
The motor bracket
1 20.6
Upper the right mounting plate of the
evaporator
1
12.2
Motor shaft sleeve right gland
1 20.7
Upper the left mounting plate of the
evaporator
1
12.3
Motor shaft sleeve left gland
1 21
Step motor
1
12.4
Motor separating board
1 22
Horizontal louver assembly
1
12.5
Indoor fan motor
1 23
Step motor
1
13
Display panel assembly
1 24
Air guide bracke
1
13.1
Display panel components
1
11
