R410A 60Hz EER 2.36 Series Service Manual
No. Part Name Quantity No. Part Name Quantity
1 Left cover 1 18.2 Temperature Sensor 1
2 Install lifting ears 2 18.3 Under the right mounting plate of the evaporator 1
3 Stepper motor 1 18.4 Under the left mounting plate of the evaporator 1
4 Left panel assembly 1 18.5 Upper the right mounting plate of the evaporator 1
5 Air guide assembly 1 18.6 Upper the left mounting plate of the evaporator 1
6 Rear Cover 1 19 Display panel components 1
7 Right panel assembly 1 19.1 Digital Tube 1
8 Stepper motor 1 19.2 Show mask 1
9 Right cover 1 19.3 Display board mounting box 1
10 Electro Control Box assembly 1 20 Back style grille assembly 2
10.1 Electro Control Board 1 20.1 Back style grille 2
10.2 Electro Control Box 1 20.2 Dust filter 2
10.3 Temperature Sensor 1 20.3 Grille buckle 4
10.4 Terminal 1 20.4 Grille screw cover 6
10.5 Short circuit Cable 1 21 Top cover parts 1
10.6 PC board isolation column 1 22 Drip tray assembly 1
10.7 Transformer 1 22.1 Drip tray foam 1
10.8 Fan Capacitor 1 22.2 Horizontal swing leaf mounting 1 1
10.9 Light board cable group 1 22.3 Horizontal swing leaf mounting 2 1
11 Electro Control Box Cover 1 22.4 Horizontal swing leaf active rod 1
12 Support bar 1 22.5 Horizontal swing leaf connecting rod 1 1
13 Piping plate 1 22.6 Wind guide blade 10
14 Motor bracket 1 22.7 Stepper motor 1
15 Centrifugal fan blade 2 23 Air guide bracket 1
16 Upper volute 3 24 Motor hoard 1
17 Fan Motor 1 25 Coupling 1
18 Evaporator component 1 26 Connecting shaft 1
18.1 Evaporator pre-welded components 1 27 Motor support assembly 1
18.1.1 Evaporator assembly 1 28 Lower volute 3
18.1.2 Evaporator output tube assembly 1 29 Middle beam welding assembly 1
18.1.3 Evaporator input tube assembly 1 30 Base assy 1
